Pepperl+Fuchs VBG-ENXK20-DMD-EV - Function Invocation

AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
The Modbus Address Table
26.9.2013
77
11.4.4 Function invocation
AS-i circuit 2
Function invocation
4x reference access data
8961 -/w function: opcode
1: Set_Operation_Mode
2: Change_Slave_Address
3: Store_Actual_Parameters
4: Store_Actual_Configuration
5: Execute_Command
6: Send_Parameter
8961 r/- function: result
0: success
32769: failure
32770: slave with 1st addr not detected
32771: slave with zero addr detected
32772: slave with 2nd addr detected
32773: delete error
32774: set error
32775: address stored temporarily
32776: extended ID1 stored temporarily
32777: error reading extended ID1
32778: parameter out of range
32779: invalid opcode
8962 r/w function: parameter 1
8963 r/w function: parameter 2
Tab. 11-58.
