AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
EtherNet/IP interface
10.7 I/O Data Object
class code: 102 (0x66)
Input and output data
1 instance for each AS-i circuit
Instance 1 equates to AS-i circuit 1
Instance 2 equates to AS-i circuit 2
attribute
ID
access rule name devicenet data typedefault data
value
100 get input data image, single and A-slaves ARRAY[16] of
USINT
101 get input data image, B-slaves ARRAY[16] of
USINT
102 get/set output data image single and A-slavesARRAY[16] of
USINT
103 get/set output data image, B-slaves ARRAY[16] of
USINT
104 get 16-bit input data slave 1 ARRAY[4] of INT
……… … …
134 get 16-bit input data slave 31 ARRAY[4] of INT
135 get/set 16-bit output data slave 1 ARRAY[4] of INT
……… … …
165 get/set 16-bit output data slave 31 ARRAY[4] of INT
Tab. 10-21.
