Pepperl+Fuchs VBG-ENXK20-DMD-EV - Displaying of Ethernet Properties; Setting of Ethernet Properties

26.9.2013
16
AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
Installation
6.5.2.1 Displaying of Ethernet properties
6.5.2.2 Setting of Ethernet properties
ETHERNET
ETHERNET
TCP/IP
MODBUS
LINK:
100 BASE-TX FDX
MAC ID:
00-16-77-00-
2E-C3
ESC
OK
ACTUAL VALUES
192. 168. 000.254
NET MASK
255. 255. 255. 0
GATEWAY
0 .0 .0 .0
ETHERNET
TCP/IP
MODBUS
ACTUAL VALUES
CONFIGURATION
IP ADDRESS
OK
ESC
ETHERNET
TCP/IP
MODBUS
ACTUAL VALUES
CONFIGURATION
OK
CONFIGURATION
DYNAMIC
CONFIGURATION
STATIC
When using DHCP, no adjustment is necessary
IP ADDRESS
192. 168. 42. 149
NET MASK
255. 255. 255. 0
GATEWAY
0 . 0 . 0. 0
If you do not have DHCP client access, please contact your network administrator. /
