AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
EtherNet/IP interface
10.9 Short Command Interface Object
class code: 104 (0x68)
1 instance
10.10 Long Command Interface Object
class code: 105 (0x69)
1 instance
For special details acc. the command interface commands see the separat manu-
al "AS-i 3.0 Command Interface".
attribute
ID
access
rule
name devicenet
data type
default
data value
100 (0x64) get/set content ARRAY[12] of USINT
command [0]
toggle-bit and AS-i circuit [1]
data [2 … 11]
Tab. 10-28.
attribute
ID
access
rule
name devicenet
data type
default
data value
100 (0x64) get/set content ARRAY [38] of USINT
command [0]
toggle-bit and AS-i circuit [1]
data [2 … 37]
Tab. 10-29.
