AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
Installation
6.5.3.1 Select command interface mode
6.5.3.2 Setting of EtherNet/IP properties
OK
ESC
MAILBOX MODE
38 BYTE
38 Byte:
Enchanced mailbox length for current device re-
vision
TCP OBJECT
ETHERNET OBJECT
MAILBOX MODE
MODBUS TCP
ETHERNET/IP X
MAILBOX MODE
36 BYTE
OK
36 Byte:
Compatibility mode for older devices
MAILBOX MODE
↓ OK
TCP/IP OBJECT
ETHERNET OBJECT
IF STATUS
IF CAPABILITY
IF CONTROL
...
USE DHCP
If you do not have DHCP client access, please contact your network administrator. /
OK
↓
OK
TCP/IP OBJECT
ETHERNET OBJECT
IP ADDRESS
192. 168. 42. 149
NET MASK
255. 255. 255. 0
GATEWAY
0 . 0 . 0. 0
IF STATUS
IF CAPABILITY
IF CONTROL
PATH TO LINK OBJ.
TCP/IP CONFIG
Restart the gateway to assume your changes
OK
↓
When using DHCP, no adjustment is necessary
