AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
EtherNet/IP interface
26.9.2013
49
CA (configuration_active): The configuration-mode is active
AAv (Auto_Address_Available): Automatic programming is possible
0: Auto-address is possible
1: Auto-address is not possible
AAs (Auto_Address_Assign): Automatic programming is allowed
S0 (LDS.0): There is an AS-i slave with address ’0’
Cok (config_ok): Configuration error:
0: no error
1: error
Hi-flags (8-bit)
2
2
2
1
2
0
AAe OL DX
Tab. 10-14.
AAe: Auto_Address_Enable
OL: Off-line
DX: Data_Exchange_Active
Operational mode (8-bit):
1: configuration mode
0: protected mode
LDS, LAS, LPS, LPF (64-bit)
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
0 7A6A5A4A3A2A1A0A
……
7 31B 30B 29B 28B 27B 26B 25B 24B
Tab. 10-15.
LDS: list of detected slaves
LAS: list of activated slaves
LPS: list of activated slaves
LPF: list of peripheral faults
