AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
EtherNet/IP interface
Coding of status bytes per OSSD
Bit [0 ... 3] State or. color
00
16
green permanent lighting
01
16
green flashing
02
16
yellow permanent lighting
03
16
yellow flashing
04
16
red permanent lighting
05
16
red flashing
06
16
grey or off
07
16
reserved
Bit [6] status or color
0 no device flashing yellow
1 at least one device flashing yellow
Bit [7] status or color
0 no device flashing red
1 at least one device flashing red
Tab. 10-31.
