AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
The Modbus Address Table
F1 - F16: flags, see tab. <Reference 1>.
Cyclic data exchange similar to the Momentum Ethernet Adapter
AS-i circuit 2: Input Data Image IDI
4x
reference
contact read access
bit value
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
„Bit“ 12345678910111213141516
18 273 - 288F1F2F3F4F5F6F7F8F9F10F11F12F13F14F15F16
19 289 - 304 slave 0/0A slave 1/1A slave 2/2A slave 3/3A
D0 D1 D2 D3 D0 D1 D2 D3 D0 D1 D2 D3 D0 D1 D2 D3
20 305 - 320 slave 4/4A slave 5/5A slave 6/6A slave 7/7A
21 321 - 336 slave 8/8A slave 9/9A slave 10/10A slave 11/11A
22 337 - 352 slave 12/12A slave 13/13A slave 14/14A slave 15/15A
23 353 - 368 slave 16/16A slave 17/17A slave 18/18A slave 19/19A
24 369 - 384 slave 20/20A slave 21/21A slave 22/22A slave 23/23A
25 385 - 400 slave 24/24A slave 25/25A slave 26/26A slave 27/27A
26 401 - 416 slave 28/28A slave 29/29A slave 30/30A slave 31/31A
27 417 - 432 not used slave 1B slave 2B slave 3B
28 433 - 448 slave 4B slave 5B slave 6B slave 7B
29 449 - 464 slave 8B slave 9B slave 10B slave 11B
30 465 - 480 slave 12B slave 13B slave 14B slave 15B
31 481 - 496 slave 16B slave 17B slave 18B slave 19B
32 497 - 512 slave 20B slave 21B slave 22B slave 23B
33 513 - 528 slave 24B slave 25B slave 26B slave 27B
34 529 - 544 slave 28B slave 29B slave 30B slave 31B
Tab. 11-33.
