AS-i 3.0 EtherNet/IP+Modbus TCP Gateway
The Modbus Address Table
Arrangement of lists LAS, LOS, LPS, LCS, DELTA and LPF
The lists LAS, LOS, LPS, LCS, DELTA und LPF are arrangement bit by bit, see
the table below:
Off-line: This output sets the master into the off-line phase.
Auto_Address_Enable!: This output blocks automatic slave-address program-
ming.
0: Auto-address is disabled
1: Auto-address is enabled
4x reference 4145 … 4208
Bit mask data
000F
h
I/O configuration
00F0
h
ID-code
0F00
h
extended ID 1-code
F000
h
extended ID 2-code
Tab. 11-45.
LAS, LOS, LPS, LCS, DELTA, LPF (16-bit)
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
7654321015141312111098
23 22 21 20 19 18 17 16 31 30 29 28 27 26 25 24
Tab. 11-46.
LAS: list of activated slaves
LOS: list of offline slaves
LPS: list of projekted slaves
LCS: list of corrupted slaves
DELTA: list of slaves with configuration error
LPF: list of periphery faults
