Pepwave MAX User Manual

http://www.pepwave.com
61
Copyright @ 2013 Pepwave
IPsec VPN Settings
Name
This field is for specifying a local name to represent this connection profile.
Active
When this box is checked, this IPsec VPN connection profile will be enabled. Otherwise, it
will be disabled.
Remote Gateway
IP Address
Enter the remote peer’s public IP address. For Aggressive Mode, this is optional..
Local Networks
Enter the local LAN subnets here. If you have defined “static routes”, they will be shown
here too.
Remote Networks
Enter the LAN and subnets that are located at the remote site here.
Main Mode
Choose this Main Mode if both IPsec peers use static IP addresses.
Aggressive Mode
Choose this Aggressive Mode if one of the IPsec peers use dynamic IP addresses.
Force UDP
Encapsulation
For UDP encapsulation to be forced regardless of the NAT-Traversal, tick this checkbox.
Pre-shared Key
This defines the peer authentication pre-shared key to be used to authenticate this VPN
connection. The connection will be up only if the pre-shared keys on each side match.
