Pepwave MAX User Manual

http://www.pepwave.com
16
Copyright @ 2013 Pepwave
5.3 Configuring the Network Environment
To ensure that Pepwave MAX works properly in the LAN environment and can access the Internet via the
WAN connections, please refer to the following setup procedures:
 LAN Configuration
For basic configuration, refer to Section 6, Connecting to Web Admin Interface.
For advanced configuration, go to Section 7, Configuration of LAN Interface(s).
 WAN Configuration
For basic configuration, refer to Section 6, Connecting to Web Admin Interface.
For advanced configuration, go to Section 8, Configuration of WAN Interface(s).
5.4 Mounting the Unit
5.4.1 Wall Mount
Pepwave MAX can be mounted on the wall by screwing. After adding the screw on the wall, slide the
MAX in the screw whole socket as indicated below.
Recommeneded Screw Specification: M3.5 x 20mm, Head Diameter 6mm, Head Thickness 2.4mm
Wall Mount
Screw Socket
Wall Mount
Screw Socket
