- Configure WAN 1 as a DHCP client.

- WAN 1 will automatically get the Gateway IP address from HD Dome 1.

- Configure WAN 2 as a Static IP and set it to 192.168.50.12.

- Configure WAN 2 Gateway to 192.168.50.2. Same as the HD Dome 2’s IP address.
