Pepwave Peplink MAX Series User Manual

LAN 1 Port
Green LED
ON POE Enabled
OFF POE Disabled
Orange LED
Blinking 10 / 100 / 1000 Mbps and Data is transferring
OFF No data is being transferred or port is not connected
Port Type Auto MDI/MDI-X ports
LAN 2-3 Port and Ethernet WAN Port
Green LED
ON 1000 Mbps
OFF
10 Mbps / 100 Mbps or port is not connected
Orange LED
ON Port is connected without traffic
Blinking Data is transferring
OFF Port is not connected
Port Type Auto MDI/MDI-X ports
Cellular Indicators
Cellular
OFF Disabled or no SIM card inserted
Blinking slowly Connecting to network(s)
Green Connected to network(s)
2.11 MAX Transit Core
2.11.1 Panel Appearance
