80 . Spectrum 100 Series User’s Guide
3. Fit the new fuse into the slot (Figure 27).
Figure 27 Fuse fitted; drawer open
4. Close the drawer.
The new fuse is now installed.
5. Reconnect the power cable and switch on the instrument.
S
p
are Fuse
Fuse
Fuse Drawer
