Unpacking and Installation . 43
Changing the Sampling Accessory
NOTE: For full installation and usage instructions for your accessory, refer to the appropriate
User’s Guide available as a pdf on the
Spectrum Two Manuals CD
(part number
L1050242).
1. If you are installing a NIRM, you will need to remove the sample compartment cover
(Figure 24), if fitted.
Open the cover, raise it to the vertical position and then lift it upwards, clear of the
instrument.
Store the cover in a safe place for future re-use.
Figure 24 Removing the sample compartment cover
2. Remove the current sampling accessory by pulling the baseplate of the accessory
towards you (Figure 25).
Figure 25 Removing the sampling accessory
compartment
Slide holder on
baseplate
