Model Views
Engine Aftertreatment System
g02384
560
Illustration 21
Typical example
(1) Cle
an emissions module (CE M)
(2) Inl
et connection
(3) Ou t
let connection
(4) M o u
nting c radle
(5) F le
xible exhaust pipe from engine to
CEM
i04340730
Engin
e Description
The Perkins 1206-E66 Industrial Engine has the
following characteristics.
•
In-line Six cylinder
•
Fou
rstrokecycle
•
Turbocharged charge cooled
Engine Specifications
Note: The front end of the engine is opposite the
flywheel end of the engine. The left and the right
si
des of the engine are determined from the flywheel
end. The number 1 cylinder is the front cylinder.
g01127295
Illustration 22
Cylinder and v alve location
(A) Exhaust valves
(B) Inlet valves
