36 SEBU8603-01
Operation Section
Features and Controls
i04201172
Monitoring System
(Table for the
Indicator lamps)
Note: When in operation the amber warning lamp
has three states, solid, flashing, and fast flashing.
The sequenc
eistogiveavisualindicationofthe
importance of the warning. Some application can
have an audible warning installed.
Ensure that the engine maintenance is carried out at
the correct intervals. A lack of maintenance can result
in illumin
ation of the warning lamp. For the correct
intervals of maintenance, refer to the Operation
and Maintenance Manual, “Maintenance Interval
Schedule”
.
Table 2
Warning
Lamp
Shutdown
Lamp
Lamp State Description of the Indication Engine Status
On On Lamp Check When the keyswitch is moved to the
ON position, the lamps come on for 2
seconds and the lamps will then go
off.
The keyswitch is in the ON position but
the engine has not yet been cranked.
Off Off
No Faults With the engine in operation, there
are no active warnings, diagnostic
codes, or event c odes.
The engine is operating with no detected
faults.
On Solid Off
Warning Level 1 warning The engine is operating normally but
there is one or more faults with the
electronic management system for the
engine.
Flashing
Off
Warning Level 2 warning The engine continues to be operated,
but the level of importance of the
warning has increased.
Depending on the particular fault and
the severity the engine may be de-rated.
The engine could be damaged if
continued to be operated.
Flashing On Engine
Shutdown
Level 3 warning
If both the warning lamp and the
shutdown lamp are in operation, this
issue indicates one of the following
conditions.
1. One or more of the shutdown
values for the engine protection
strategy has been exceeded.
2. A serious active diagnostic code
has been detected.
After a short time period, the engine
may shut down.
The engine is either shutdown or an
engine shutdown is imminent. O ne or
more monitored engine parameters
have exceeded the limit for an engine
shutdown. This pattern of lamps can be
caused by the detection of a serious
active diagnostic code.
