SEBU8603-01 33
Operation Section
Gauges and Indicators
Service Hour Meter – The gauge indicates
total operating hours of the engine.
Indicator Lam
ps
There is four indicator lamps that are available.
•
Shutdown Lamp
•
Warning Lam
p
•
Wait to Start Lamp
•
Low Oil Pressure Lamp
For inform
ation, refer to this manual, “Monitoring
System (Table for the Indicator Lamps)” for the
sequence of operation of the shutdown lamp and the
warning l
amp.
The function of the wait to start lamp is automatically
controll
ed at engine start-up.
The function of the low oil pressure lamp is controlled
by the en
gine ECM. If low oil pressure is detected,
the lamp will be illuminated. The reason for the
illumination of the low-pressure lamp should be
investi
gated immediately.
All lamps will illuminate for 2 seconds in order to
check t
hat the lamps are functioning when the
keyswitch is turned to the ON position. If any of the
lamps stay illuminated, the reason for illumination
should
be investigated immediately.
Instr
ument panels and Displays
In order to monitor the engine a wide verity of
instr
ument panels are available. These instrument
panels can contain the indicator lamps and the
gauges for the application.
Also available are mini power displays and
performance monitors. These displays and monitors
can s
how the operator the following engine
information.
•
The
system configuration parameters
•
The customer specified parameters
•
Diagnostic codes
•
Ev
ent codes
•
Coolant temperature
•
Oil temperature
•
Oil pressure
•
Intake temperature
•
Intake pressure
•
Atmospheric
pressure
•
Fuel temperature
