Operational controls
7 - 1
7 Operational controls
7.01 On/Off switch
● Turn the machine on and off by pressing
the On/Off switch 1 to “1” for on and
“0“ for off. When the machine is on, the
control lamp 1 in the switch is lit.
The On/Off switch in the
illustration is that of machines
with Quick motors. When
using other motors, other
switches may be used.
7.02 Knuckle switch on machine head
● Key 1 is for reversing the sewing
direction (on machines with backtacker
-911/35).
Fig. 7 - 01
Fig. 7 - 02
1
1
