Preparation
9 - 1
9 Preparation
All regulations and instructions in this Instruction Manual are to be adhered to.
Special attention is to be paid to all safety regulations!
All preparatory work must only be carried out by appropriately trained
personnel. When carrying out preparatory work, the machine is to be separated
from the power supply by turning off the On/Off switch or by removing the
plug from the socket.
9.01 Inserting the needle
Turn the machine off!
Only use the following needle systems:
Top feed version -706/81: 438
Top feed version -706/83: 438-35
● Bring the needle bar into its highest
position.
● Loosen screw 1.
● Insert needle 2 as far as possible.
● The long needle-groove must be facing
the front.
● Tighten screw 1.
The choice of needle depends
on the model of the machine
and the thread and material to
be used (see chapter 3.03
Needle and thread).
2
3
Fig. 9 - 01
1
