Adjustment
4
2
5
1
3
11.05.30 Bottom feed dog height
Requirement
With the stitch length set at “0“ and the needle bar position at 0.25 past tdc (hole 3) the
bottom feed dog must be in the middle of the needle plate cutout and be touching the feed
dog height-adjustment gauge along its entire length.
1.1 mm
2
1
4
Fig. 11 - 32
● Position the feed dog adjustment gauge underneath the presser foot with the cutout
facing downwards.
● Lower the presser foot onto it.
● Loosen screws 2 and 4
● Press the feed dog carrier up and position the feed dog in the middle of the needle plate
cutout.
● Turn lifting crank 1 and clamp bush 3 in accordance with the requirement.
● Tighten screws 2 and 4.
3
11 - 32
