Adjustment
11.05.31 Clearance between presser foot and needle plate
Requirement
With the hand lever raised the needle must enter exactly in the middle of the needle hole
in the presser foot and the clearance between the needle plate and the presser foot must
be 7 mm.
● Set the zigzag stitch lever at “0“ and the needle position adjustment lever at “middle“.
● Allow the presser foot to rest on the needle plate. Loosen nut 10 and reduce the presser
on the presser foot bar by turning screws 1 and 11.
● Tighten nut 10.
● Loosen screw 2. Push out pin 3 and pivot connecting joint 4 out of the fork of the feed
lever.
● Bring lever 5 to its outer point of reversal.
● Place the feed dog adjustment gauge underneath the presser foot with its notch facing
downwards.
3
7-14-32
1
3
2
4
6
7
8
5
7 mm
9
11
10
11 - 33
Fig. 11 - 34
