Preparation
9 - 11
9.09.05 Braking the top fabric ply or intermittently applying fullness
● Turn adjustment wheel 1 to “+“ as far as it will go.
● Turn adjustment wheel 2 until the desired level of stretch (red numbers) is at marking 3.
● Turn adjustment wheel 1 back until the desired level of fullness (green number) is
at marking 3.
● Adjust the stitch length (see chapter 9.08 Adjusting the stitch length).
The sum of the selected fullness level and the stitch length must not exceed
4.5 because more than this lessens the stitch length.
When the left pedal is in resting position the machine stretches the top fabric
layer constantly. By activating the left pedal the level of fullness set on
adjustment wheel 1 is sewn into the top fabric ply (see chapter 7.03 Pedal).
Fig. 9 - 19
Fig. 9 - 18
