Operational controls
7 - 4
7.07 Stitch-length adjustment wheel
● The stitch length can be altered by
turning the stitch-length adjustment
wheel 1.
The current stitch-length can be
seen on scale 2.
7.08 Adjustment wheels for the top feed
● Adjustment wheel 1 (1st setting)
This adjustment wheel is for adjusting
the setting with which the machine is
to do most of its work.
Green area = Apply fullness
Red area = Stretch
Zero = Normal sewing
(top and bottom
feeds work with
same feed motion)
● Adjustment wheel 2 (2nd setting)
This adjustment wheel is for setting a
value which is different from the first
setting and which can be called up
using the second treadle.
(see chapter 7.03 Pedal)
1
0
2
3
4
Fig. 7 - 07
1
2
2
1
Fig. 7 - 08
1
0
2
3
4
