Preparation
9 - 7
9.09 Adjusting the top feed
9.09.01 Normal sewing
● Turn adjustment wheel 1 to “+“ as far as it will go.
● Turn adjustment wheel 2 until “0“ is at marking 3.
● Turn adjustment wheel 1 back until “0“ is at marking 3.
● Adjust the stitch length (see chapter 9.08 Adjusting the stitch length).
In normal sewing mode the bottom and top feeding motions are the same
length.
1
0
2
3
4
1
2
3
Fig. 9 - 10
Fig. 9 - 11
