Installation and commissioning
8 - 1
Fig. 8 - 01
8 Installation and commissioning
This machine may only be installed and commissioned by qualified specialists!
All relevant safety regulations are to be adhered to!
If the machine is delivered without a table, the frame and table top used must
be able to support the weight of the machine and the motor. The table must
guarantee a sufficient level of stability - even during sewing.
8.01 Installation
Connections for electrical and compressed air supplies must be available at the machine’s
location.
A firm, horizontal surface and adequate lighting must also be guaranteed where the
machine is installed.
The table top is lowered for packaging. The following is a description of how to
adjust the table top height.
8.01.01 Adjusting the height of the table top
● Loosen screws 1 and 2.
● Adjust the height of the table top as desired and tighten screews 1 fimly.
● Adjust the position of the right pedal ergonomically and tighten screw 2.
● The left pedal can be adjusted by means of chain 3.
1
1
3
2
