1 Introduction and Basic Operation
21
Charging IntelliVue Cableless Measurement
Devices
All IntelliVue Cableless Measurement Devices and Auxiliary Devices except the CL Hotspot are
battery powered and need to be recharged using the IntelliVue CL Charging Station. The batteries are
built in and can only be exchanged by trained service personnel.
To charge a battery, place the device onto a charger slot on the charging station. The NBP Pod and
Transmitter should always be placed on one of the slots in the upper row. The battery power indicators
will supply information about the charge status.
WARNING
• Always use the supplied power cord with the grounded mains plug to connect the charging station
to a grounded AC mains socket. Never adapt the mains plug from the charging station to fit an
ungrounded AC mains socket.
• Do not use AC mains extension cords or multiple portable socket outlets. If a multiple portable
socket outlet without an approved isolation transformer is used, the interruption of its protective
grounding may result in enclosure leakage currents equal to the sum of the individual ground
leakage currents, so exceeding allowable limits.
• Do not connect any devices that are not supported as part of a system.
Battery Power Indicators
There are various indications which help you keep track of the battery power status:
• LEDs on the charging station slots
• battery status information on both the device's and the charging station's display
• INOP messages
• battery symbol on the patient monitor's screen (when assigned to a patient monitor)
• battery symbol in GuardianSoftware (when assigned to a patient in GuardianSoftware)
The indicators always show the remaining capacity in relation to the battery's actual maximum capacity,
which may lessen as the battery ages. You can see the actual capacity in the
Battery menu.
