11-4
Technical specifications
Alarms Table 11-4 lists the adjustable alarm ranges and resolutions. Table 9-3 on
page 9-7 describes other, nonadjustable alarms.
Menu window
settings
Table 11-4: Adjustable alarm ranges and resolutions
Parameter Range Resolution Factory default
Hi Rate (High Rate
Alarm)
5 to 90 BPM 1 BPM 30 BPM
Lo Rate (Low Rate
Alarm)
1 to 89 BPM 1 BPM 10 BPM
Hi V
T
(High Tidal Vol-
ume Alarm)
200 to 3500 mL
BTPS
5 mL 2500 mL
Lo V
T
(Low Tidal Vol-
ume Alarm)
OFF, 5 to 1500 mL
BTPS
5 mL OFF
HIP (High Inspiratory
Pressure Alarm)
5 to 50 cmH
2
O1 cmH
2
O50 cmH
2
O
LIP (Low Inspiratory
Pressure Alarm)
OFF, 1 to 40 cmH
2
O1 cmH
2
OOFF
Lo
E
(Low Minute
Ventilation Alarm)
OFF, 0.1 to
99.0 L/min BTPS
0.1 L/min OFF
LIP T (Low Inspiratory
Pressure Delay Time
Alarm)
5 to 60 sec 1 sec 20 secs
Table 11-5: Menu window settings and ranges
Parameter Range
Brightness 1 to 5
Loudness 1 to 10
Mask/ET Selection ET/Trach, 1, 2, 3, 4, Other
Exhalation Port Selection • FEP (Philips Respironics Filtered Exhalation Port)
• DEP (Philips Respironics Disposable Exhalation
Port
• Whisper Swivel (Philips Respironics Whisper
Swivel),
• PEV (Philips Respironics Plateau Exhalation Valve),
• Other (Other Exhalation Port),
• None (No circuit exhalation port)
Screen Lock Off, On
Auto-Trak+ (optional) Trigger: Normal, +1 to +7.
E-Cycle: -2 to -1, Normal, +1 to +6
