Technical specifications
11-9
Alarm-related
specifications
Other specifications
Table 11-12: Alarm-related specifications
Parameter Specification
Delay time from the onset of the
alarm condition to the point that
the representation of the alarm
condition leaves the signal out-
put port
< 10 ms from onset of the alarm condition to the
transmission of the signal
< 500 s until alarms received from the ventilator are
displayed on the IntelliVue patient monitor. This de-
lay is in addition to the alarm detection and process-
ing delays of the external device.
Remote alarm delay time The time it takes the message to appear on the re-
mote alarm depends on the characteristics of the de-
vice.
Maximum time from the alarm
condition triggering event to the
generation of an alarm signal
All alarms except those listed below: < 10 s
• Patient disconnect alarm: 11 s
• Proximal pressure line disconnect alarm: 15 s
• Low Inspiratory Pressure (LIP) alarm:
user-configurable from 5 to 60 s
• Check vent: Blower temperature high: 10 minutes
Mean delay, or the sum of mean
delays, from the triggering event
to the generation of an alarm sig-
nal
All alarms except those listed below: < 5 s
• Cooling fan failure alarm: 10 s
• Blower temperature alarm: 10 s
• ADC wraparound: 6 s
Audio alarm loudness
*
* In accordance with 3rd Edition testing methods
Highest volume setting: Average sound pressure level
is approximately 76 dB(A)
Lowest volume setting: Average sound pressure level
is approximately 62 dB(A)
High-priority auditory alarm sig-
nal sound pressure level range,
measured per
ISO 3744:2010 ANSI/
Average sound power level is approximately 54 dB(A)
measured at the ventilator
Average sound pressure level is approximately 46
dB(A) measured 1 m from the ventilator
Table 11-13: Other specifications
Parameter/Characteristic Specification
Expected ventilator service life 10 years
Flow delivery 150 L/min at 40 cmH
2
O at 1951 m (6400 ft) altitude
(10% degradation in flow at 2286 m (7500 ft))
Flow range 0 to 240 L/min BTPS
