11-8
Technical specifications
Electrical
specifications
Accessory
requirements
NOTE: Any part that is added to the patient circuit changes the compliance
and resistance of the ventilator breathing system. To achieve the
ventilator performance specified in this manual, the ventilator
breathing system must meet the specifications listed in Table 11-11.
Table 11-10: Electrical specifications
Parameter Specification
AC voltage 100 to 240 VAC
AC frequency 50/60 Hz
AC power 300 VA
Battery PN 1076374: 14.4 V, 11.0 Ah, 163 Wh
Maximum system current draw: 11 A
Charge voltage: +16.9 V maximum
Operating time: 360 minutes (6 hours) under normal
conditions
Table 11-11: Accessory Requirements
Parameter Specification
Compliance For volume accuracy requirements, the patient circuit
compliance should be 0.98 mL/cmH
2
O.
For all other performance requirements except
volume accuracy, the maximum compliance of the
circuit can be up to 2.8 mL/cmH
2
O.
Resistance Maximum resistance of the breathing circuit and at-
tachments: 2.9 cmH
2
O at 60 L/min.
Bacteria filter Dead Space: 66 ml
Bacterial/Viral Filter Efficiency: >99.99%
Resistance (@ 0.5 L/s): 0.7 cmH
2
O (hPa)/L/s
Male Connector: 15 mm I.D./22 mm O.D.
Female Connector: 22 mm I.D.
