Philips V60 - Patient Data

Technical specifications
11-3
Patient data
Table 11-3: Patient data ranges, resolutions, and accuracies during ventilation
Parameter Range Resolution Accuracy
Patient data window
Breath phase/trigger indicator Spont, Timed, Exhale Color-coded display: Spont -
turquoise, Timed - orange, Ex-
hale - blue
N/A
PIP 0 to 50 cmH
2
O1 cmH
2
O± 2 cmH
2
O
Pt. Leak 0 to 200 L/min BTPS 1 L/min N/A
Pt. Trig 0 to 100% 1% ± 10%
Rate 0 to 90 BPM 1 BPM ± 1 BPM
T
I
/T
TOT
0% to 91% 1% ± 5%
Tot.Leak 0 to 200 L/min BTPS 1 L/min N/A
E
0 to 99.0 L/min BTPS 0.1 L/min ± 15% or 0.3 L/min (whichev-
er is greater)
V
T
0 to 3500 mL BTPS 1 mL ± 15% for volumes above
200 mL
Note: Accuracy specification
was measured with patient
circuit PN 582073
Waveform window
P waveform 0 to 50 cmH
2
O Time axis: 1 second N/A
waveform -240 to 240 L/min BTPS Time axis: 1 second N/A
V waveform 0 to 3500 mL BTPS Time axis: 1 second N/A
