Setting up the ventilator for use
5-5
NOTE: This circuit setup is recommended for noninvasive ventilation. It is
also recommended for high flow therapy when using the AC611 high
flow nasal cannula with FEP Connector to block the exhalation port.
Figure 5-1: Patient circuit, with heated-wire and humidification for
noninvasive ventilation or high flow therapy
Proximal pressure line
Ventilator
outlet
Bacteria filter
Proximal
pressure
port
Humidifier
Oxygen sensor tee
