FL SWITCH 2000 / FL NAT 2000
106 / 226
PHOENIX CONTACT 108997_en_04
General data
Mounting type DIN rail
Type AX Book type
Functional earth ground The functional ground of the module is achieved when the
module is snapped onto the DIN rail.
Weight 435 g
Housing material Polycarbonate fiber reinforced
MAC address table 8k
MTTF 365.63 Years (SN 29500 standard, temperature 25 °C,
operating cycle 21 % (5 days a week, 8 hours a day))
MTTF 218.22 Years (SN 29500 standard, temperature 40 °C,
operating cycle 34.25 % (5 days a week, 12 hours a day))
MTTF 31.7 Years (SN 29500 standard, temperature 55 °C, operating
cycle 100 % (7 days a week, 24 hours a day))
Signal contact
Output name Digital output
Control voltage range 12 VDC ... 57 VDC
Current carrying capacity typ. 100 mA
max. 0.7 A (1 minute)
Connection data
Connection method Push-in spring connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.25 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.25 mm²
Conductor cross section flexible max. 1.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 9 mm
Interface: Ethernet (RJ45)
Number of interfaces 16
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100 Mbps
Transmission length 100 m (per segment)
