Phoenix Contact FL SWITCH 2005 Installation And Startup Guide

Technical data
108997_en_04 PHOENIX CONTACT 175 / 226
5.49 FL SWITCH 2508
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion A
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Conformity with EMC directives
Approvals / Certificates
UL, USA UL 61010-1, Ed. 3
UL, Canada CSA C22.2 NO. 61010-1-12, Ed. 3
Ordering data
Order designation FL SWITCH 2508
Order No. 1043484
Pcs./Pkt. 1
Dimensions (nominal sizes in mm)
Width 128 mm
Height 110 mm
Depth 69 mm
Ambient conditions
Degree of protection IP20
Protection class III (VDE0106)
Degree of pollution 2
Ambient temperature (operation) -40 °C ... 70 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Air pressure (operation) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Air pressure (storage/transport) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Free from substances that could impair the application of
coating
Yes
