Technical data
108997_en_04 PHOENIX CONTACT 189 / 226
5.55 FL SWITCH 2504-2GC-2SFP
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) in acc. with IEC 60068-2-6: 5g, 150 Hz
Vibration (storage/transport) 5g, 150 Hz, in acc. with IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Interference emission EN 61000-6-2 EN 61000-6-4 (interference) Class A
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion A
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
EN 61000-6-2 EN 61000-6-4 (conducted interference) Class A
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
EN 61000-6-2 EN 61000-6-4 (conducted interference) Class A
Approvals / Certificates
UL, USA UL 61010-1, Ed. 3
UL, Canada CSA C22.2 NO. 61010-1-12, Ed. 3
Ordering data
Order designation FL SWITCH 2504-2GC-2SFP
Order No. 1088872
Pcs./Pkt. 1
Dimensions (nominal sizes in mm)
Width 128 mm
Height 110 mm
Depth 69 mm
