Technical data
108997_en_04 PHOENIX CONTACT 121 / 226
5.28 FL SWITCH 2212-2TC-2SFX
UL, Canada CSA C22.2 NO.60079-0, Ed.3 / CSA C22.2 NO.60079-7:16
UL, USA/Canada Class I, Div. 2, Groups A, B, C, D T4
Class I, Zone 2, IIC T4
Further approvals cULus Listed, ABS, DNV GL, LR, NK, RINA, PROFINET
Approvals / Certificates
Ordering data
Order designation FL SWITCH 2212-2TC-2SFX
Order No. 2702907
Pcs./Pkt. 1
Dimensions (nominal sizes in mm)
Width 85 mm
Height 130 mm
Depth 115 mm
Ambient conditions
Degree of protection IP20
Protection class III, VDE 0106
Degree of pollution 2
Ambient temperature (operation) -40 °C ... 70 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Air pressure (operation) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Air pressure (storage/transport) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Free from substances that could impair the application of
coating
Yes
General data
Mounting type DIN rail
Type AX Book type
Functional earth ground The functional ground of the module is achieved when the
module is snapped onto the DIN rail.
Weight 480 g
Housing material Polycarbonate fiber reinforced
MAC address table 8k
