Phoenix Contact FL SWITCH 2005 Installation And Startup Guide

FL SWITCH 2000 / FL NAT 2000
24 / 226
PHOENIX CONTACT 108997_en_04
3.2.4 Installing the devices
3.2.4.1 Selecting the conductors
The devices are supplied with a Push-in connector.
Observe the specifications for suitable conductors and ferrules:
Table 3-5 Selection of conductors/ferrules/screwdrivers
Conductor Push-in Screw
Conductor cross-section, rigid, minimum 0.14 mm
2
Conductor cross-section, rigid, maximum 1.5 mm
2
Conductor cross-section, flexible,
minimum
0.14 mm
2
Conductor cross-section, flexible,
maximum
1.5 mm
2
Conductor cross-section, flexible, with
ferrule without plastic sleeve, minimum
0.25 mm
2
Conductor cross-section, flexible, with
ferrule without plastic sleeve, maximum
1.5 mm
2
Conductor cross-section, flexible, with
ferrule with plastic sleeve, minimum
0.25 mm
2
Conductor cross-section, flexible, with
ferrule with plastic sleeve, maximum
0.75 mm
2
0.5 mm
2
Suitable ferrule without plastic sleeve:
maximum conductor cross-section
1.5 mm
2
Suitable ferrule without plastic sleeve:
maximum conductor cross-section
0.75 mm
2
(color code: gray in
accordance with
DIN 46228)
0.5 mm
2
(color code: white in
accordance with
DIN 46228)
Suitable screwdriver Slot-headed screwdriver
Blade thickness: 0.4 mm
Blade width: 2.5 mm
Recommended: SZS 0,4X2,5 VDE,
Order No. 1205037
Conductor cross-section, AWG,
minimum
24
Conductor cross-section, AWG,
maximum
16
Stripping length 9 mm
