FL SWITCH 2000 / FL NAT 2000
68 / 226
PHOENIX CONTACT 108997_en_04
5.8 FL SWITCH 2205
Vibration (operation) 2g, according to IEC60068-2-6
Vibration (storage/transport) 2g, criterion 1 according to IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Mechanical tests
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Conducted noise emission EN 61000-6-2 EN 61000-6-3 (conducted emissions) Class B
Interference emission EN 61000-6-2 EN 61000-6-3 (noise emission) Class B
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion B
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Approvals / Certificates
UL, USA UL 61010-1, Ed.3 / UL 61010-2-201, Ed.1
UL, Canada CSA C22.2 NO.61010-2-201:14, Ed.1 / CSA C22.2 NO.61010-
1-12, Ed.3
Further approvals cULus Listed, EAC
Ordering data
Order designation FL SWITCH 2205
Order No. 2702326
Pcs./Pkt. 1
Dimensions (nominal sizes in mm)
Width 45 mm
Height 130 mm
Depth 115 mm
Ambient conditions
Degree of protection IP20
Protection class III, VDE 0106
Degree of pollution 2
Ambient temperature (operation) -40 °C ... 70 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
