Page #208 background imageLoading...
Page #208 background image
FL SWITCH 2000 / FL NAT 2000
208 / 226
PHOENIX CONTACT 108997_en_04
5.63 FL SWITCH 2708
Max. current consumption 0.52 A (U
S
= min, T
amb
= max)
Maximum power dissipation for nominal condition 4.68 W (U
S
= min, T
amb
= max)
Test section for one minute 500 VDC
Supply voltage
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) in acc. with IEC 60068-2-6: 5g, 150 Hz
Vibration (storage/transport) 5g, 150 Hz, in acc. with IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Conducted noise emission EN 61000-6-3 (conducted emissions) Class B
Interference emission EN 61000-6-3 (conducted emissions) Class B
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion B
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Ordering data
Order designation FL SWITCH 2708
Order No. 1106615
Pcs./Pkt. 1
Dimensions (nominal sizes in mm)
Width 60 mm
Height 226 mm
Depth 46 mm
Ambient conditions
Degree of protection IP65/IP66/IP67
Protection class III (VDE0106)
Ambient temperature (operation) -40 °C ... 70 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 5 % ... 95 %
Permissible humidity (storage/transport) 5 % ... 95 %
