Phoenix Contact FL SWITCH 2005 Installation And Startup Guide

Mounting and installation
108997_en_04 PHOENIX CONTACT 27 / 226
3.3 FL SWITCH 20xxF
3.3.1 Device dimensions
Figure 39 Dimensions of the 8-port version in a flat housing
3.3.2 Elements of the devices
Figure 310 Elements of the FL SWITCH 20xxF devices
Table 3-7 Key for FL SWITCH 20xxF
Number Meaning
1 Connection of the supply voltage
2 RJ45 ports
3 Smart mode button
4 Diagnostic and status indicators
5 Slot for optional microSD card
2
1
5
4
3
