FL SWITCH 2000 / FL NAT 2000
212 / 226
PHOENIX CONTACT 108997_en_04
5.65 FL NAT 2008
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion B
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Conformity with EMC directives
Ordering data
Order designation FL NAT 2008
Order No. 2702881
Pcs./Pkt. 1
Dimensions (nominal sizes in mm)
Width 45 mm
Height 130 mm
Depth 115 mm
Ambient conditions
Degree of protection IP20
Protection class III, VDE 0106
Ambient temperature (operation) 0 °C ... 60 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Air pressure (operation) 86 kPa ... 108 kPa (1500m above sea level)
Air pressure (storage/transport) 86 kPa ... 108 kPa
Free from substances that could impair the application of
coating
Yes
General data
Mounting type DIN rail
Type AX Book type
Functional earth ground The functional ground of the module is achieved when the
module is snapped onto the DIN rail.
Weight 220 g
Housing material Polycarbonate fiber reinforced
MAC address table 8k
MTTF 507.8 Years (SN 29500 standard, temperature 25 °C,
operating cycle 21 % (5 days a week, 8 hours a day))
MTTF 246.55 Years (SN 29500 standard, temperature 40 °C,
operating cycle 34.25 % (5 days a week, 12 hours a day))
MTTF 56.66 Years (SN 29500 standard, temperature 55 °C,
operating cycle 100 % (7 days a week, 24 hours a day))
