Phoenix Contact FL SWITCH 2005 Installation And Startup Guide

Technical data
108997_en_04 PHOENIX CONTACT 211 / 226
MAC address table 8k
MTTF 461.15 Years (SN29500 standard, temperature25°C,
operating cycle21%)
MTTF 149.69 Years (SN29500 standard, temperature40°C,
operating cycle34.25%)
MTTF 19.78 Years (SN29500 standard, temperature70°C, operating
cycle100%)
General data
Connection data
Connection method M12 connector (L-coded)
Interface: Ethernet
Number of interfaces 8
Connection method M12 connectors, X-coded
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100/1000 Mbps
Transmission length 100 m (per segment)
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 9 VDC ... 57 VDC
Typical current consumption 260 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 0.77 A (U
S
= min, T
amb
= max)
Maximum power dissipation for nominal condition 6.93 W (U
S
= min, T
amb
= max)
Test section for one minute 500 VDC
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) in acc. with IEC 60068-2-6: 5g, 150 Hz
Vibration (storage/transport) 5g, 150 Hz, in acc. with IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Conducted noise emission EN 61000-6-3 (conducted emissions) Class B
Interference emission EN 61000-6-3 (conducted emissions) Class B
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
