Phoenix Contact FL SWITCH 2005 Installation And Startup Guide

FL SWITCH 2000 / FL NAT 2000
204 / 226
PHOENIX CONTACT 108997_en_04
5.61 FL SWITCH 2608
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 19.2 VDC ... 32 VDC
Typical current consumption 490 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 820 mA (U
S
= min, T
amb
= max)
Maximum power dissipation for nominal condition 14.88 W (U
S
= max, T
amb
= max)
Test section for one minute 500 VDC
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) in acc. with IEC 60068-2-6: 5g, 150 Hz
Vibration (storage/transport) 5g, 150 Hz, in acc. with IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Conducted noise emission EN 61000-6-2 EN 61000-6-4 (conducted interference) Class A
Interference emission EN 61000-6-2 EN 61000-6-4 (interference) Class A
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
Immunity to EF EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion
A
Immunity to ESD EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B
Immunity to surge EN 61000-6-2 EN 61000-4-5 (surge) Criterion A
Immunity to conducted interference EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A
Approvals / Certificates
UL, USA UL 61010-1, Ed. 3
UL, Canada CSA C22.2 NO. 61010-1-12, Ed. 3
Ordering data
Order designation FL SWITCH 2608
Order No. 1106500
Pcs./Pkt. 1
