Technical data
108997_en_04 PHOENIX CONTACT 207 / 226
Ambient conditions
Degree of protection IP65/IP66/IP67
Protection class III (VDE0106)
Ambient temperature (operation) -40 °C ... 70 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 5 % ... 95 %
Permissible humidity (storage/transport) 5 % ... 95 %
Air pressure (operation) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Air pressure (storage/transport) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Free from substances that could impair the application of
coating
Yes
General data
Mounting type Wall mounting
Type AX Stand-alone
Weight 1150 g
Housing material Zinc die-cast
MAC address table 8k
MTTF 461.15 Years (SN29500 standard, temperature25°C,
operating cycle21%)
MTTF 149.69 Years (SN29500 standard, temperature40°C,
operating cycle34.25%)
MTTF 19.78 Years (SN29500 standard, temperature70°C, operating
cycle100%)
Connection data
Connection method M12 connector (L-coded)
Interface: Ethernet
Number of interfaces 8
Connection method M12 connectors, D-coded
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100 Mbps
Transmission length 100 m (per segment)
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 9 VDC ... 57 VDC
Typical current consumption 180 mA (at U
S
= 24VDC and 25°C ambient temperature)
