Phoenix Contact FL SWITCH 2005 Installation And Startup Guide

FL SWITCH 2000 / FL NAT 2000
174 / 226
PHOENIX CONTACT 108997_en_04
Transmission physics Copper
Transmission speed 10/100 Mbps
Transmission length 100 m (per segment)
Interface: Ethernet (RJ45)
Interface: SFP module
Number of interfaces 2
Connection method SFP ports
Transmission physics Depending on the SFP module
Transmission speed 100 Mbps (full duplex)
Transmission length up to 40 km (depending on the SFP module used)
Interface: Ethernet (combo)
Number of interfaces 2
Connection method SFP or RJ45 ports
Note on the connection method Auto negotiation and autocrossing
Transmission physics Depending on the SFP module
Transmission speed 10/100 Mbps (full duplex)
Transmission length up to 40 km (Depending on the fiber/SFP module used)
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 19.2 VDC ... 32 VDC
Typical current consumption 320 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 490 mA (U
S
= min, T
amb
= max)
Maximum power dissipation for nominal condition 9.31 W (U
S
= max, T
amb
= max)
Test section for one minute 500 VDC
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) in acc. with IEC 60068-2-6: 5g, 150 Hz
Vibration (storage/transport) 5g, 150 Hz, in acc. with IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
Conformity with EMC directives
Electromagnetic compatibility Conformance with EMC Directive 2014/30/EU
Conducted noise emission EN 61000-6-2 EN 61000-6-4 (conducted interference) Class A
Interference emission EN 61000-6-2 EN 61000-6-4 (interference) Class A
Immunity to burst EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A
