Technical data
108997_en_04 PHOENIX CONTACT 119 / 226
Air pressure (operation) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Air pressure (storage/transport) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Free from substances that could impair the application of
coating
Yes
Ambient conditions
General data
Mounting type DIN rail
Type AX Book type
Functional earth ground The functional ground of the module is achieved when the
module is snapped onto the DIN rail.
Housing material Polycarbonate fiber reinforced
MAC address table 8k
MTTF 365.63 Years (SN 29500 standard, temperature 25 °C,
operating cycle 21 % (5 days a week, 8 hours a day))
MTTF 218.22 Years (SN 29500 standard, temperature 40 °C,
operating cycle 34.25 % (5 days a week, 12 hours a day))
MTTF 31.7 Years (SN 29500 standard, temperature 55 °C, operating
cycle 100 % (7 days a week, 24 hours a day))
Signal contact
Output name Digital output
Control voltage range 12 VDC ... 57 VDC
Current carrying capacity typ. 100 mA
max. 0.7 A (1 minute)
Connection data
Connection method Push-in spring connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.25 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.25 mm²
Conductor cross section flexible max. 1.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 9 mm
Interface: Ethernet (RJ45)
Number of interfaces 14
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
