Phoenix Contact FL SWITCH 2005 Installation And Startup Guide

Technical data
108997_en_04 PHOENIX CONTACT 143 / 226
Signal contact
Output name Digital output
Control voltage range 12 VDC ... 57 VDC
Current carrying capacity typ. 100 mA
max. 0.7 A (1 minute)
Connection data
Connection method Push-in spring connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.25 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.25 mm²
Conductor cross section flexible max. 1.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 9 mm
Interface: Ethernet (RJ45)
Number of interfaces 14
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100/1000 Mbps
Transmission length 100 m (per segment)
Interface: SFP module
Number of interfaces 2
Connection method SFP ports
Transmission physics Depending on the SFP module
Transmission speed 100/1000 Mbps (full duplex)
Transmission length up to 80 km (Depending on the fiber/SFP module used)
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 12 VDC ... 57 VDC
Typical current consumption 460 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 2 A (U
S
= Min, T
amb
= Max, DO
I
= Max)
Maximum power dissipation for nominal condition 15.6 W (U
S
= Min, T
amb
= Max, DO
I
= Max)
Test section for one minute 500 VDC
