Technical data
108997_en_04 PHOENIX CONTACT 155 / 226
Ambient conditions
Degree of protection IP20
Protection class III (VDE0106)
Degree of pollution 2
Ambient temperature (operation) -40 °C ... 70 °C
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Air pressure (operation) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Air pressure (storage/transport) 79 kPa ... 108 kPa up to 2000m above mean sea level (Without
derating)
Free from substances that could impair the application of
coating
Yes
General data
Mounting type DIN rail
Type AX Block design
Functional earth ground The functional ground of the module is grounded when it is
snapped onto a grounded DIN rail
Weight 610 g
Housing material Stainless steel 1.4301
MAC address table 8k
Signal contact
Output name Relay
Actuation voltage range max. 60 VDC
Current carrying capacity max. 0.2 A
Connection data
Connection method Push-in spring connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.2 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.2 mm²
Conductor cross section flexible max. 2.5 mm²
Conductor cross section AWG min. 24
Conductor cross section AWG max. 16
Stripping length 10 mm
