Technical data
108997_en_04 PHOENIX CONTACT 191 / 226
Interface: Ethernet (RJ45)
Number of interfaces 4
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100/1000 Mbps
Transmission length 100 m (per segment)
Interface: SFP module
Number of interfaces 2
Connection method SFP ports
Transmission physics Depending on the SFP module
Transmission speed 100/1000 Mbps (full duplex)
Transmission length up to 80 km (depending on the SFP module used)
Interface: Ethernet (combo)
Number of interfaces 2
Connection method SFP or RJ45 ports
Note on the connection method Auto negotiation and autocrossing
Transmission physics Depending on the SFP module
Transmission speed 10/100/1000 Mbps (full duplex)
Transmission length up to 80 km (Depending on the fiber/SFP module used)
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 19.2 VDC ... 32 VDC
Typical current consumption 270 mA (at U
S
= 24VDC and 25°C ambient temperature)
Max. current consumption 390 mA (U
S
= min, T
amb
= max)
Maximum power dissipation for nominal condition 7.2 W (U
S
= max, T
amb
= max)
Test section for one minute 500 VDC
Mechanical tests
Mechanical tests Free fall in accordance with EN61131-2
Vibration (operation) in acc. with IEC 60068-2-6: 5g, 150 Hz
Vibration (storage/transport) 5g, 150 Hz, in acc. with IEC 60068-2-6
Shock (operation) 30g (EN60068-2-27)
