Technical data
108997_en_04 PHOENIX CONTACT 215 / 226
Weight 230 g
Housing material Polycarbonate fiber reinforced
MAC address table 8k
MTTF 494.02 Years (SN 29500 standard, temperature 25 °C,
operating cycle 21 % (5 days a week, 8 hours a day))
MTTF 235.18 Years (SN 29500 standard, temperature 40 °C,
operating cycle 34.25 % (5 days a week, 12 hours a day))
MTTF 29.73 Years (SN 29500 standard, temperature 70 °C,
operating cycle 100 % (7 days a week, 24 hours a day))
General data
Signal contact
Output name Digital output
Control voltage range 9 VDC ... 57 VDC
Current carrying capacity typ. 100 mA
max. 0.7 A (1 minute)
Connection data
Connection method Screw connection
Note on the connection method Use only copper connecting cables providing the permitted
temperature range (-40°C ... 75°C).
pluggable Yes
Conductor cross section solid min. 0.08 mm²
Conductor cross section solid max. 1.5 mm²
Conductor cross section flexible min. 0.08 mm²
Conductor cross section flexible max. 1.5 mm²
Conductor cross section AWG min. 28
Conductor cross section AWG max. 16
Stripping length 7 mm
Interface: Ethernet (RJ45)
Number of interfaces 8
Connection method RJ45
Note on the connection method Auto negotiation and autocrossing
Transmission physics Copper
Transmission speed 10/100 Mbps
Transmission length 100 m (per segment)
Supply voltage
Supply voltage 24 VDC (redundant)
Residual ripple 3.6 V
PP
(within the permitted voltage range)
Supply voltage range 9 VDC ... 57 VDC
Typical current consumption 185 mA (at U
S
= 24VDC and 25°C ambient temperature)
